Sealing Wire

We manufacture sealing wires from different kinds of wire in miscellaneous packings.

Starting materials:

	Iron wire, galvanized
	Iron wire, plastic-covered
	Copper-, brass-, or non-rusting steel wire
	Plastic wire
	Aluminum wire

In the following, you find an overview about our standard-delivery-program.

Other dimensions or packings on request.

The stated total-diameter can vary because of allowable tolerances of the raw material. The stated tensile strength always refers to the core wire.

Sealing Wire - made from galvanized iron wire

Make up:
plastic spools:
of 250 g, 500 g, 1 kg, 100 m, 400 m

cut lengths:
from 10 cm upwards
in bundles of 1.000 pieces each or 1 kg

on request:
coils from 100 g to approx. 10 kg

Sealing Wire - galvanized

Type	Description	Diameter Ø [mm]	Core-wire Ø [mm]	Lapped wire Ø [mm]	~m/kg	Tensile strength ~ [N]
	0.25/0.20	0.65	0.25	0.20	1300	19
	0.30/0.25	0.80	0.30	0.25	800	28
	0.30/0.30	0.90	0.30	0.30	680	28
	0.40/0.30	1.00	0.40	0.30	500	49
	0.45/0.30	1.05	0.45	0.30	430	63
	0.50/0.30	1.10	0.50	0.30	385	77
	0.50/0.45	1.40	0.50	0.45	250	77
	0.50/0.50	1.50	0.50	0.50	220	77
	0.70/0.30	1.30	0.70	0.30	250	151
	0.70/0.45	1.60	0.70	0.45	185	151
	0.70/0.50	1.70	0.70	0.50	160	151
	0.45/2x0.45	1.35	0.45	2x0.45	225	63
	7x0.20/0.45	1.45	7x0.20	0.45	300	86

Sealing Wire - made from copper-, brass-, stainless steel wire

Make up:
plastic spools:
of 250 g, 500 g, 1 kg, 100 m, 400 m

cut lengths:
from 10 cm upwards
in bundles of 1.000 pieces each or 1 kg

on request:
coils from 100 g to approx. 10 kg

Sealing Wire - made from copper / brass / stainless steel

Type	Description	Diameter Ø [mm]	Core-wire Ø [mm]	Lapped wire Ø [mm]	~m/kg	Tensile strength ~ [N]
copper brass stainless steel	0.30/0.30	0.90	0.30	0.30	593 606 672	19 23 49
copper brass stainless steel	0.50/0.30	1.10	0.50	0.30	356 369 419	54 66 138
copper	0.70/0.30	1.30	0.70	0.30	213	104
copper	0.70/0.45	1.60	0.70	0.45	167	104

Sealing Wire - made from aluminum wire

Make up:
plastic spools:
of 100 m, 200 m, 400 m

cut lengths:
from 10 cm upwards
in bundles of 1.000 pieces each

Sealing Wire - made from aluminum wire

Description	Diameter Ø [mm]	Core-wire Ø [mm]	Lapped wire Ø [mm]	~kg/1.000 m	Tensile strength ~ [N]
0.30/0.30	0.90	0.30	0.30	0,480	28
0.50/0.30	1.10	0.50	0.30	0,850	77
0.50/0.50	1.50	0.50	0.50	1,480	77

Sealing Wire - made from plasticcovered iron wire

Make up:
plastic spools:
of 100 m, 200 m, 400 m

cut lengths:
from 10 cm upwards
in bundles of 1.000 pieces each

Available colours:
see below

Sealing Wire - made from plastic-covered iron wire

Type	Description	Diameter Ø [mm]	Core-wire Ø [mm]	Lapped wire Ø [mm]	~m/kg	Tensile strength ~ [N]
	0.60/0.60	1.80	0.60	0.60	500	35
	0.60/2x0.60	1.80	0.60	2x0.60	430	35

Sealing Wire with plastic core

Make up:
plastic spools:
of 100 m, 200 m, 400 m, 1.700 m

cut lengths:
from 10 cm upwards
in bundles of 1.000 pieces each

Available colours:
see below

Sealing Wire with plastic core

* available lapped wires: iron wire (galvanized), copper-, brass-, stainless steel wire

Type	Description	Diameter Ø [mm]	Core-wire Ø [mm]	Lapped wire Ø [mm]	~m/kg	Tensile strength ~ [N]
	0.50/0.30*	1.10	0.50	0.30	1300	90
	0.30/0.60	1.50	0.30	0.60	800	35
	0.50/0.60	1.70	0.50	0.60	680	90

Available colours of the plastic- & plasticcovered wires

Wire	Colour
full-plastic core-wire 0.3 mm Ø	transparent
full-plastic core-wire 0.5 mm Ø	transparent, white, red, blue, yellow, black, green
all wires with 0.6 mm Ø (plasticcovered iron wire)	white, red, blue, yellow, black, green, orange
